2002 Husqvarna CR250

2002 Husqvarna CR250

General Specifications

ModelHusqvarna CR 250
Year2002
CategoryMotocross
Engine TypeSingle-cylinder, 2-stroke
WeightApproximately 102 kg dry

Engine

Displacement249.3 cc
Bore x Stroke66.4 x 72 mm
Compression Ratio
Fuel SystemMikuni TMX 38 carburettor | Replacement Options
IgnitionElectronic CDI with variable advance
Spark PlugNGK BR8EG
Spark Plug Gap0.6-0.7 mm
Cooling SystemLiquid cooled
Starting SystemKick starter

Transmission

Transmission5-speed manual
ClutchWet multi-disc
Final DriveChain

Dimensions

Overall Length
Overall Width
Overall Height
WheelbaseApproximately 1475 mm
Ground ClearanceApproximately 340 mm
Seat HeightApproximately 950 mm
Fuel CapacityApproximately 9 litres

Chassis

FrameChrome-molybdenum steel single-backbone frame
Front Tyre80/100-21 | Tyre Size Guide
Rear Tyre110/90-19 | Tyre Size Guide

Suspension

Front SuspensionMarzocchi 45 mm upside-down telescopic fork | Fork Oil Levels
Front Suspension TravelApproximately 300 mm
Rear SuspensionSachs monoshock with progressive linkage, adjustable preload, compression and rebound damping
Rear Suspension TravelApproximately 320 mm
Fork OilSAE 7.5W fork oil

Brakes & Wheels

Front BrakeHydraulic single disc, 260 mm
Rear BrakeHydraulic single disc, 220 mm
Front Wheel Size21 inch
Rear Wheel Size19 inch

Service Data

Fuel TypePremium unleaded petrol with 2-stroke oil premix
Premix Information3% (approximately 1:33) during running-in; not less than 2% (1:50) after running-in | Premix Calculator
Gearbox OilSAE 10W-40 motorcycle oil; approximately 0.8 litre
Air FilterWashable oiled foam element
Service NotesCompetition motorcycle requiring frequent maintenance. Clean and re-oil the foam air filter regularly, change gearbox oil frequently, inspect the piston, rings and small-end bearing at competition service intervals, keep the exhaust power-valve mechanism clean, and inspect the rear suspension linkage and steering-head bearings for wear.

2002 Husqvarna CR 250 – Continuing the Italian Two-Stroke Tradition

The 2002 Husqvarna CR 250 was primarily an evolutionary update of the previous year's machine rather than a completely new generation. Built during Husqvarna's Italian era, it remained a distinctive alternative to the Japanese 250 two-strokes and KTM's increasingly successful SX range. Its combination of a powerful two-stroke engine, steel chassis and European suspension gave it a character all its own.

The 249.3 cc liquid-cooled engine retained its 66.4 x 72 mm bore and stroke and used a 38 mm Mikuni TMX carburettor. An exhaust power-valve system broadened the engine's usable power delivery. On surviving bikes, carburettor wear, incorrect jetting and ageing intake components can significantly affect performance, so the MXOwners carburettor information and replacement options can be useful during restoration.

The chassis continued with long-travel Marzocchi upside-down forks and a Sachs rear shock operating through a progressive linkage. After more than two decades, suspension and chassis bearings deserve careful inspection; the MXOwners motorcycle bearing finder can help when replacing worn components.

For today's owner, returning a 2002 CR 250 to good mechanical condition is usually more worthwhile than modifying it. A fresh top end, clean power valve, properly serviced carburettor, fresh gearbox oil and correctly maintained foam air filter will restore much of the performance these bikes were known for. Correct fuel-oil mixture is equally important, and the two-stroke premix calculator makes preparing the required mixture straightforward. The 2002 CR 250 remains an uncommon and interesting survivor from Husqvarna's Italian-built motocross years.
